Hastelloy Fasteners Manufacturer, Hastelloy Round Bar Price,
Hastelloy Pipes Supplier
in
India
D.R Steel is a high-quality Hastelloy Manufacturer & Supplier in
India.We
supply a wide variety
of Hastelloy Plate & Sheet
ranging from 0.1 mm to 100 mm thickness, with a maximum width of 2500
mm. We have full control of the quality and uniformity of the Hastelloy Sheet from each
manufacturer's process, with ISO 9001 certifications. Our Hastelloy Plate meets or exceeds
international standards for quality, safety, and environmental responsibility.
Hastelloy Angle Supplier, Hastelloy Channel Stockist,
Hastelloy Tubes Manufacturer in India
D.R Steel is a noteworthy Hastelloy Manufacturer in India. We supply a diverse
range of
surface finishes for industrial or aesthetic purposes to our clients, such as 2B, 2D, BA, No. 1,
and No.4 options. Our Hastelloy Round Bar is known for their exceptional resistance to
pitting,
crevice corrosion, and stress-corrosion cracking, ensuring long-lasting reliability, especially
for the most demanding operating environments. We are also a leading Sheet, Plate & Coil
Manufacturer in India.
Hastelloy Specification
| Hastelloy Specification |
| Hastelloy Types |
Hastelloy Bars, Hastelloy Pipes and Tubes, Hastelloy Flanges, Hastelloy
Fasteners, Hastelloy Pipe Fitting, Hastelloy Sheets Plates Coils. |
| Standard |
ASTM / ASME SB 168, ASTM / ASME SB 424 , ASTM / ASME SB 443, UNS N06600 /
Werkstoff Nr. 2.4816 |
| Sheet & Plate Size |
0.1 mm to 100 mm thick upto 2500 mm width & upto 8000 mm length
available with NACE MR 01-75s. |
| Pipe & Tube Size |
1/2″NB to 30″NB & 1/2″OD TO 36 |
| Pipe Fittings Size |
1/2"NB to 36"NB, ANSI B 16.9 |
| Bars Size |
5mm" to 500mm |
| Flanges Size |
1/2″ (15 NB) to 48″ (1200NB) ANSI B 16.5 |
| Fasteners Size |
3 mm to 200 mm |
| Surface |
2B, 2D, BA, NO. 1, NO. 4, NO.8, 8K, Mirror, Checkered, Embossed, Sand Blast,
Brush, Etching |
| Grades |
C22, C276, B2, B3, C4, C-22, C2000, X |
Types of Hastelloy
Chemical Composition of Hastelloy
|
Chemical Composition
|
| Grade |
C |
Mn |
Si |
S |
Co |
Ni |
Cr |
Fe |
Mo |
P |
| C276 |
0.010 max |
1.00 max |
0.08 max |
0.03 max |
2.50 max |
50.99 min* |
14.50 – 16.50 |
4.00 – 7.00 |
15.00 – 17.00 |
0.04 max |
| C22 |
0.010 max |
0.50 max |
0.08 max |
0.02 max |
2.50 max |
50.015 min* |
20.00 – 22.50 |
2.00 – 6.00 |
12.50 – 14.50 |
0.02 max |
| B2 |
0.02 max |
1.0 max |
0.1 max |
0.03 max |
1.0 max |
Bal |
1.0 max |
2.0 max |
26 – 30 |
0.04 max |
Mechanical Properties of Hastelloy
|
Mechanical Properties
|
| Element |
Density |
Melting Point |
Tensile Strength |
Yield Strength (0.2%Offset) |
Elongation |
| Hastelloy C276 |
8.89 g/cm3 |
1370 °C (2500 °F) |
Psi – 1,15,000 , MPa – 790 |
Psi – 52,000 , MPa – 355 |
40 % |
| Hastelloy C22 |
8.69 g/cm3 |
1399 °C (2550 °F) |
Psi – 1,00,000 , MPa – 690 |
Psi – 45000 , MPa – 310 |
45 % |
| Hastelloy B2 |
9.2 g/cm3 |
1370 °C (2500 ºF ) |
Psi – 1,10,000 , MPa – 760 |
Psi – 51000 , MPa – 350 |
40 % |
Applications of Hastelloy
01
Chemical
02
Oil & Gas
03
Pharmaceutical
04
Aerospace
05
Power Plant
06
Defence
We are Manufacturer, Supplier, Exporter and Stockist of Hastelloy.
-D R Steels
